PERKINS TIER 4 INTERIM 854E-E34TA ENGINES
The 5D-T4i tractors are powered by the new Perkins 854E-E34TA four-cylinder turbo-aftercooled engines with two-valve cylinder head and electronic common rail injection system that provide power outputs from 85 to 102 hp. These 3.4-liter engines utilize an innovative exhaust gas recirculation system (EGR) in conjunction with a diesel particulate filter (DPF) to meet the Tier 4 Interim emission regulations. These units incorporate advanced technologies that improve tractor performance in terms of power, torque and fuel economy. Fully reshaped to reflect the new Landini family style, the tilt-up hood opens wide to provide easy access to the engine compartment for routine service and maintenance
| 5-090 D HC | 5-100 D HC | 5-110 D HC | |
|---|---|---|---|
| Perkins Tier4 Interim Direct-injection engine | 854E-E34TA | 854E-E34TA | 854E-E34TA |
| Max.Power ISO [CV / kW] | 85 / 62,5 | 95 / 70 | 102 / 75 |
| Rated speed | 2200 | 2200 | 2200 |
| Max Torque NM | 354 | 395 | 420 |
| Displacement / No of cylinders | 3400/4 TURBO AFTERCOOLER | 3400/4 TURBO AFTERCOOLER | 3400/4 TURBO AFTERCOOLER |
| Fuel tank capacity Litres | 102 | 102 | 102 |
WEIGHTS AND DIMENSIONS (IN RUNNING ORDER)
| 5-090 D HC | 5-100 D HC | 5-110 D HC | |
|---|---|---|---|
| Front tires | 9.5R48 | 9.5R48 | 9.5R48 |
| Rear tires | 9.5R48 | 9.5R48 | 9.5R48 |
| Lenght (with ballast) MM | 167.5 (4255) | 167.5 (4255) | 167.5 (4255) |
| Min. Width MM | 2020 | 2020 | 2020 |
| Wheelbase 2WD/4WD MM | 87.6/87.8 (2225/2230) | 87.6/87.8 (2225/2230) | 87.6/87.8 (2225/2230) |
| Height to rops MM | 110 (2795) | 110 (2795) | 110 (2795) |
| Height over cab MM | 110.5 (2804) | 110.5 (2804) | 110.5 (2804) |
| Ground Clearence 4 WD | 79.5 (2020) | 79.5 (2020) | 79.5 (2020) |
| Weight 4WD (Without ballast) Platform/Cabine KG | 8030/8470 (3650/3850) | 8030/8470 (3650/3850) | 8030/8470 (3650/3850) |
