so simple, so efficient
The new C-Max series is a range of simple and modern tractors. Available in both platform and cab versions, the C-Max tractors are powered by ecofriendly, fuel-efficient Perkins 1104D engines that deliver 74, 83, 92.5 and 102 hp/ISO and meet the Tier 3 emission regulations. Featuring an advanced fuel injection system that optimizes air-fuel mixture and enhances combustion efficiency, these engines combine high power and torque levels with low running costs. The C-Max 110 is also available in a turbocharged version powered by a Tier0 1104-44T engine that develops 106.8 hp/ISO. The C-Max also offers a high-clearance version (HC) for both the two- and four-wheel drive models. Rotating the rear drop-down final drives and using special front axles and tall, narrow tyres result in higher belly clearance, making this tractor ideal for working in specialty crops such as rice fields and interrow crops.
PERKINS DIRECT-INJECTION ENGINE
The C-Max tractors are powered by ecofriendly, fuel-efficient Perkins 1104D engines that deliver 83, 92.5 and 102 hp/ISO and meet the Tier 3 emission regulations. The C-Max 110 is also available in a turbocharged version powered by a Tier0 1104-44T engine that develops 106.8 hp/ISO. The hood, fully restyled to reflect the new family styling, provides unobstructed view in all directions and opens wide to provide easy access to the engine compartment for service and maintenance.
| C110 MAX | C90 MAX | C100 MAX | C110 MAX | |
|---|---|---|---|---|
| TIER 0 | TIER 3 | TIER 3 | TIER 3 | |
| PERKINS DIRECT-INJECTION ENGINE | 1104A-44T | 1104D-44 | 1104D-44TA | 1104D-44TA |
| MAX. POWER ISO HP/KW | 106.8/78.5 | 83 / 61 | 92,5 / 68 | 102 / 75 |
| MAX. TORQUE NM | 400 | 352 | 363 | 416 |
| DISPLACEMENT/NR. OF CYLINDERS cm3 | 4400/4 TURBO | 4400/4 TURBO | 4400/4 TURBO AFTERCOOLER | 4400/4 TURBO AFTERCOOLER |
| FUEL TANK CAPACITY LTR | 102 | 102 | 102 | 102 |
Synchro Shuttle transmission
The synchro shuttle transmission offers four gears in three ranges providing 12 speeds forward and 12 reverse. A 30 km/h transmission is available with either an underdrive (standard on the 2WD version) or a creep speed option. An overdrive option with 40 km/h maximum speed is also available for the 4WD models.
Cab "Deluxe"
The fully-glazed Deluxe cab with its roof-mounted air conditioning system and logicallyarranged controls offers the operator a functional and comfortable working environment for maximum ease of operation. Offering a wide choice of models and versions, the C-Max range is designed for productivity, versatility and comfort.
The hydraulic system
The mechanical power lift provides a maximum total fl ow rate of 82 litres/min. The mechanical power lift, equipped with a cat. 2 three-point linkage provides position, draft, intermix and fl oating control functions while ensuring a maximum lifting capacity of 4350 kg. The tractor can be optionally equipped with a rear lever allowing the operator to control raising and lowering of the lift from the ground. The system features up to 4 auxiliary valves, two controlled by a joystick for front loader use and two operated by a lever located beside the driver’s seat.
dimensions and weights
| C110 MAX (T0) STD | C90 MAX (T3) STD HC | C100 MAX (T3) STD HC | C110 MAX (T3) STD HC | |
|---|---|---|---|---|
| FRONT TYRES 4WD | 12.4-24 | 12.4-24 | 13.6-24 | 380/70 R24 |
| REAR TYRES | 16.9-30 | 16.9-30 | 16.9-34 | 480/70 R34 |
| A - LENGTH (WITH BALLAST WEIGHT) MM | 4136 | 4136 | 4136 | 4160 |
| B - MIN. WIDTH MM | 1945 | 1945 | 2034 | 2110 |
| C - FRONT TRACK ADJUSTMENT 4WD MM | 1553-1954 | 1608-1954 | 1540-1967 | 1740-2167 |
| C - REAR TRACK ADJUSTMENT MM | 1508-1908 | 1515-2008 | 1612-2012 | 1612-2012 |
| D - WHEELBASE 2WD/4WD MM | 2365-2340 | 2341/2316 2255/2230 | 2341/2316 2255/2230 | 2365/2340 2255/2230 |
| E - HEIGHT OVER CAB MM | 2518 | 2518 | 2558 | 2563 |
| F - GROUND CLEARANCE 4WD MM | 425 | 425 | 475 | 475 |
| WEIGHT (WITHOUT BALLAST WEIGHTS) 4WD + (150KG CAB) KG | 3450 | 3330 3460 | 3330 3460 | 3450 3500 |
